Notes

A Guide to Makefiles

“This is my makefile guide. There are many like it, but this one is mine.”

A completely unrelated picture of Carney Pond during the sunset

Beware that I haven’t actually tested most of the examples here, so there might be some mistakes.

Why?

There are already better guides to makefiles, but most people don’t have time for that and just want to copy the right text to make their project work, so that’s what this one is for. Links to the documentation are peppered throughout so you can figure out where this seemingly arcane stuff is defined.

Even experienced software developers often mess up makefiles (often requiring workarounds on the part of package maintainers), so I’ll also try to document some of the footguns I’ve seen in the wild.

What is make?

Make is a command-line tool that is used to build outputs given a set of rules and dependencies. There are a few implementations of it, but the one that everyone uses is GNU Make.

Building a C program

In general, programs written in C are built with a process similar to the one below.

C build process
$ # Run the compiler on each source file
$ cc -c src/main.c -Iinclude -o src/main.o
$ cc -c src/foo.c -Iinclude -o src/foo.o
$ # Link the resulting object files
$ cc src/main.o src/foo.o -lSDL2 -o my-program

There are obviously a bunch of ways this could be automated and improved, but makefiles are one of the most standard ways to do this.

Writing a naïve makefile

Makefile
#!/usr/bin/make -f

all: my-program

my-program: src/main.o src/foo.o
        cc src/main.o src/foo.o -lSDL2 -o my-program

src/main.o: src/main.c
        cc -c src/main.c -Iinclude -o src/main.o

src/player.o: src/player.c
        cc -c src/foo.c -Iinclude -o src/foo.o

.PHONY: all

As you can see, a makefile is just a list of rules that map inputs (”prerequisites”) to outputs (”targets”). The standard target “all” specifies what to build by default, and it is considered a phony target because it does not result in the creation of a file.

The line at the top is a shebang. It is optional, but it allows the file to be run with “./Makefile” if it is marked as executable.

Writing a better makefile

Makefile
#!/usr/bin/make -f

CFLAGS ?= -Iinclude
LDFLAGS ?= -lSDL2
SRC = $(wildcard src/*.c)
OBJ = $(SRC:.c=.o)

all: my-program

my-program: $(OBJ)
        cc $^ $(LDFLAGS) -o $@

clean:
        rm -f my-program $(OBJ)

.PHONY: all clean

This is much closer to what is seen in the real world.

This is good enough for most situations, but makefiles are often expected to install the program as well.

Writing installation targets

Programmers screw up their installation rules through various methods, but the most common ones I’ve seen are the following.

Makefile
#!/usr/bin/make -f

PREFIX ?= /usr/local
BINDIR ?= $(PREFIX)/bin
CFLAGS ?= -Iinclude
LDFLAGS ?= -lSDL2
SRC = $(wildcard src/*.c)
OBJ = $(SRC:.c=.o)

all: my-program

my-program: $(OBJ)
        cc $^ $(LDFLAGS) -o $@

clean:
        rm -f my-program $(OBJ)

install:
        install -m755 my-program $(DESTDIR)$(BINDIR)/my-program

uninstall:
        rm -f $(DESTDIR)$(BINDIR)/my-program

.PHONY: all clean install uninstall

This is generally what installation targets should look like. The documentation suggests defining INSTALL_PROGRAM and INSTALL_DATA variables. However, I’ve almost never seen this in makefiles, and it doesn’t simplify anything, so I don’t do it.

You’ll note that the paths are defined in PREFIX and BINDIR variables. Package tooling will often do something like “make PREFIX=/tmp/staging/usr” internally, so it’s important to leave the build and installation configurable through standard variables if possible.

Libraries can be a bit more complicated.

Building a library

I often find the following mistakes in makefiles for dynamic libraries.

Here is an example that attempts to correctly build and install a library.

Makefile
#!/usr/bin/make -f

VERSION := 1.2.0 # The full library version
SOVER := 1 # Assuming versions 1.X.X maintain API compatibility

PREFIX ?= /usr/local
ifeq ($(shell uname -m), x86_64)
        LIBDIR ?= $(PREFIX)/lib64
else
        LIBDIR ?= $(PREFIX)/lib
endif
INCLUDEDIR ?= $(PREFIX)/include

CFLAGS ?= -Iinclude -fPIC
LDFLAGS ?= -lSDL2
SRC = $(wildcard src/*.c)
OBJ = $(SRC:.c=.o)
HEADERS = $(wildcard include/foo/*.h)

all: libfoo.a libfoo.so.$(VERSION)

libfoo.a: $(OBJ)
        ar ruv $@ $^
        ranlib $@

libfoo.so.$(VERSION): $(OBJ)
        cc $^ -shared -Wl,-soname,libfoo.so.$(SOVER) $(LDFLAGS) -o $@

clean:
        rm -f libfoo.so* libfoo.a $(OBJ)

install: all
        install libfoo.a $(DESTDIR)$(LIBDIR)/libfoo.a
        install libfoo.so.$(VERSION) $(DESTDIR)$(LIBDIR)/libfoo.so.$(VERSION)
        ln -sf $(DESTDIR)$(LIBDIR)/libfoo.so.$(VERSION) $(DESTDIR)$(LIBDIR)/libfoo.so.$(SOVER)
        install -d $(DESTDIR)$(INCLUDEDIR)/foo
        install -m0644 $(HEADERS) $(DESTDIR)$(INCLUDEDIR)/foo

uninstall:
        rm -f $(DESTDIR)$(LIBDIR)/libfoo.a
        rm -f $(DESTDIR)$(LIBDIR)/libfoo.so*
        rm -rf $(DESTDIR)$(INCLUDEDIR)/foo

.PHONY: all clean install uninstall

Note that the dynamic library is installed with a version number attached and a separate symlink for the SONAME. That is generally the standard way of installing shared library images.

Website makefile example

To demonstrate the versatility of makefiles, here’s one that doesn’t even process code.

Makefile
#!/usr/bin/make -f

# This gets a list of pages.
# Note that this has no extension, so both .html and .md files will be found.
PAGES = $(wildcard pages/*)
OUTPUT = $(addprefix dist/,$(notdir $(PAGES:.md=.html)))

# Here, the "all" target has an action.
# In this case, it copies files from a "static" folder to the "dist" folder.
all: $(HTML) dist/sitemap.xml
        cp -urv static/. dist

# The pipe means "dist" is an order-only prerequisite.
# This means the target must exist, but we don't need to rebuild if it changes.
dist/sitemap.xml: $(HTML) | dist
        build-sitemap.sh $^ $@ # The HTML files are passed to the sitemap script.

# This is a general rule to template markdown pages.
dist/%.html: pages/%.md tmp/openring.html  | dist
        template-markdown.sh $< $@

# This is a general rule to template HTML pages.
# Note that this rule has the same target as the previous one.
# Based on the prerequisites, make will determine which action to run.
dist/%.html: pages/%.html tmp/openring.html | dist
        template-html.sh $< $@

# Note that this will trigger the openring build rule if it's not yet compiled.
tmp/openring.html: tmp openring-template.html openring/openring
        openring/openring \
                -s https://some-website.com/feed.xml \
                < templates/openring.html \
                > tmp/openring.html

# If we include openring as a git submodule, we could use this makefile to build it automatically.
# In makefile-based C projects, make -C module-name is used in the exact same way.
openring/openring:
        go build -C openring

dist:
        mkdir dist

tmp:
        mkdir tmp

# This is analogous to an "install" rule.
upload: dist
        lftp -c "set ftp:list-options -a;\
                open '$(shell cat credentials.txt)';\
                lcd dist;\
                cd public_html;\
                mirror --reverse"

clean:
        rm -rf dist tmp

.PHONY: clean upload

This makefile builds a Go program (openring), uses shell scripts to process a fictional website with markdown and HTML files, and allows the user to upload the website via FTP. I’m not claiming that makefiles are an ideal way to build websites — just that make can be used to deal with more complicated build steps.

This might seem silly, but a lot of tedious processes can be automated with makefile shenanigans.

This is tedious. Why bother?

The main benefit is that you get a lot of control over your build process, and makefiles make it easy to do things like build multi-language projects, apply weird processing to your inputs and outputs, handle submodules, etc. They also map very closely to the actual commands run on the system which make them easy to debug.

Most people prefer to use more featureful build drivers like CMake and Meson that provide package resolution, configuration, dependency checking, and other trappings. I personally don’t find that they make my life easier unless I’m integrating with other projects that use those systems or the build process is gnarly. Different strokes for different folks, I guess.
